4 Cavilities Full Automatic Bottle Molding Machine
1. Intelligent operation and maintenance to ensure stable operation
The machine's remote control and diagnostic functions enable technicians to access the machine's operating system from anywhere in the world. Through a secure network connection, they can remotely monitor the production process, adjust parameters and troubleshoot. This not only saves time and cost for on-site maintenance, but also ensures that the machine can quickly resume normal operation when problems occur, minimizing the impact on production plans.
2. Customized advantages to meet diverse needs
We are well aware that each beverage and juice brand has its own unique packaging needs. Our PET automatic blow molding machine offers a wide range of customization capabilities to meet these diverse needs. Whether it is a unique bottle shape inspired by a brand logo, a special size bottle body for a limited edition product, or a bottle body with specific features such as a built-in straw holder, our engineering team can work closely with customers to develop customized molds and production solutions.
The surface treatment of the bottle can also be customized to enhance the brand image. Options include matte, glossy, frosted or textured treatments, as well as the application of advanced printing technologies such as offset printing, screen printing or digital printing. This allows us to create high-quality, eye-catching bottles that effectively attract consumers' attention.
In addition, the equipment can be configured to produce bottles with different types of necks and caps, ensuring compatibility with a wide range of filling and capping equipment. Whether it is a standard screw cap, snap cap or flip cap, our equipment can produce bottles that meet the specific requirements of different beverage and juice products.
3. Full-cycle service, guarding the development of enterprises
Our commitment to customer success runs through the entire life cycle of the PET automatic blow molding machine. Before purchase, our expert pre-sales team will provide detailed technical consultation to help customers analyze production needs, select the most suitable equipment model, and design a customized production line layout. We provide virtual demonstrations and factory tours to give customers a comprehensive understanding of the performance and functions of the equipment.
During the installation and commissioning phase, our professional technicians will visit the site to ensure that the equipment is properly installed and calibrated for optimal performance. We provide in-depth training programs for operators and maintenance personnel, covering everything from basic machine operation and parameter settings to advanced troubleshooting and maintenance techniques.
In terms of after-sales service, our global service network ensures timely and efficient support. Our service centers are located in major industrial areas around the world, and our technicians can quickly respond to customer inquiries and technical issues. We provide 24/7 emergency support, scheduled maintenance contracts, and a comprehensive spare parts inventory to ensure long-term smooth operation of the machine.
In short, our PET automatic beverage and juice blow molding machine is a comprehensive and innovative solution that integrates advanced technology, efficient production, intelligent operation, customization, and excellent service. It is your ideal choice for beverage and juice manufacturers who want to improve production efficiency, reduce costs, improve product quality, and gain a competitive advantage in the market. Contact us now to find out how our machines can transform your beverage packaging production and drive your business development.
| TechnicalParameters | ZPA-1L-2 | ZPA-2L-2 | ZPA-1L-4 | ZPA-2L-4 | ZPA-1L-6 | ZPA-2L-6 | |
| Cavity | 2 | 2 | 4 | 4 | 6 | 6 | |
| Host Machine Parameter |
Clamping Force | 35000 | 45000 | 48000 | 48000 | 56000 | 65000 |
| Mold Route | 90 | 110 | 90 | 125 | 90 | 125 | |
| Stretching Rod Route | 300 | 400 | 260 | 330 | 260 | 330 | |
| Boctomn llold Route | 50 | 50 | 50 | 50 | 50 | 50 | |
| Bottle Spacing | 76.2 | 114.3 | 76.2 | 114.3 | 76.2 | 114.3 | |
| Bottle Preform Number | 66 | 52 | 95 | 82 | 106 | 92 | |
| Prodncts Parameter |
Max Capacty | 660 | 1500 | 600 | 1500 | 600 | 1500 |
| Max Bottle Boby Height | 260 | 330 | 260 | 330 | 260 | 330 | |
| Max Bottle Body Diameter | 68 | 105 | 68 | 105 | 68 | 105 | |
| MaxBottle Preformn Height |
100 | 140 | 100 | 140 | 100 | 140 | |
| Max Bottle Mouth Diameter |
38 | 38 | 38 | 38 | 38 | 38 | |
|
Eleetrical Parameter |
Capacty | 2500 | 2000 | 4500 | 4000 | 7200 | 6000 |
| Heating Oven Quantity | 2*2 | 4*4 | 4*4 | 5*5 | 4*4 | 5*8 | |
| Heating Lamp Quantity | 2*8 | 4*8 | 4*7 | 5*9 | 4*8 | 5*9 | |
| Heating Confguration Power | 32 | 48 | 42 | 72 | 64 | 90 | |
| Total Power Capedity | 32 | 48 | 42 | 72 | 64 | 90 | |
| Voltage | 380V50HZ | 380V50HZ | 380V50HZ | 380V50HZ | 380V50HZ | 380V50HZ | |
| Air source Parameter |
Worling Pressure | 0.7-0.9 | 0.7-0.9 | 0.7-0.9 | 0.7-0.9 | 0.7-0.9 |
| Blowing Pressure | 2 5-3.0 | 2 5-3.0 | 2 5-3.0 | 2 5-3.0 | 2 5-3.0 | |
| Air Capacitly Consumption | 2.4/30 | 2.4/30 | 3.6/30 | 3.6/30 | 5.0/30 | |
| Total Powwer | 30 | 30 | 45 | 45 | 60 | |
| Cooling Chiler Parameter | Ternperature | 9-13 | 9-13 | 9-13 | 9-13 | 9-13 |
| Pressure | 0.4 | 0.4 | 0.4 | 0.4 | 0.4 | |
| Rated Power | 3 | 3 | 5 | 5 | 5 | |
| Dimenson | Host Machine Size | 2700*1800 | 3300*1800 | 3900*1800 | 4800*2200 | 4200*2100 |
1 .stable and accurate running at high speed,adopt more stable and advanced micro-computer PLC control system.
2. production process is fully automated, with the advantages of low investment, highefficiency,easy operation, simple maintenance and safety.
3. suitable for flexible production of quantity and various bottle shape,wide range ofapplications,meet customer needs.
4. manual and automatic methods of operation, human-machine interface control. simple operation.
5. servo transmission system, high positioning accuracy, fast speed stability and good reliability.
6. less than 0.2% scrap rate for finished bottle.
DAWSON MACHINE & MOULD GROUP
located in Zhangjiagang city, have more than 18 years' experience in the field of plastic machinery,injection molding machine, blow molding machine, PeT blow molding machine, injection blow moldingmachine, during the past 18 years, we always force our energy into new areas of plastic machinery,plastic packaging machinery, to update the technology, to learn advanced experience,to confirm new theory and new design, we are forming a unique competitive advantage of our owns.The machines from our company carry good quality and effective after-sales service, upon the market,customers from more than 45 countries, we provide complete solution for your plastic industrybusiness, as well as all sorts of technical support & after-sale services!
FAQ
Q: Can we visit your factory?
Sure. We located in Zhangjiagang city which is very near Shanghai. For overseas customers, you can fly to Shanghai Pudong International Airport. We can pick you up in the Airport. (or Hongqiao International Airport. ) We also provide visit online by video.
Q: How can we get the exact price of plastic machine?
Contact us with the products size, shape, annual quantity and photo if possible. We can recommend our machine models with quotation.
Q: Do you provide any spare parts with machine?
Yes, we offer all necessary spare parts before shipment.(contact us for packing list )
Q: How about your after-sale service ?
We offer manual instruction and engineer training before loading,after shipment we provide 24 HRS online support, video technical support or field installation assist.
Q: What is the lead time?
For customized machine, it takes about 45-50 days after deposit. For stock machine, fast shipment. ( The actual production cycle will vary according to the degree of customization.)
Q: What is the warranty period for your machine ?
12 months warranty for components and technical support .
Q: Do you provide custom machines?
Most of our machines are customized. Our goal is efficiency and stable performance. We design the machines according to customers products to meet customer' needs.
Q: How can we install the machine when it arrives?
We can send experienced technicians to customer's country for guiding the installation and commission the machine, also train the customer's employees.
Q: What's ZOE PACK's advantage?
ZOE PACK provide customers with turnkey projects. Including plant design, plastic machine and mold installation, debugging, also we can source the auxiliary equipment for customers. We can ship the full set of machines after testing in our factory. It will save a lot of cost and time.
ZOE PACK will be your reliable friend in China, and we will always do our best to give you max support!
